36
Arbitrary Waveform Generator
(MP720781, MP720783 & MP720857)
Characteristics
Description
Waveform Frequency
Sine 0.1Hz~25MHz
Square
0.1Hz~5MHz
Ramp
0.1Hz~1MHz
Pulse
0.1Hz~5MHz
EXP
0.1Hz~5MHz
Sampling
125MSa/s
Amplitude(50Ω)
0.01Vpp ~ 2.5Vpp
DC offset(High Z)
±(2.5V – Amplitude Vpp/2)
Frequency Resolution
0.01%
Channel
1
Waveform Depth
8k
Vertical Resolution
14 bit
Output Impedance
50 Ω
