33
Characteristics
Description
Horizontal
Sampling rate
range
0.25 Sa/s～250 MSa/s
Waveform
interpolation
(Sinx)/x
Sweep speed
range (S/div)
MP720780
MP720781
MP720782
MP720783
5ns/div - 1000s/div, Stepping in
the 1-2-5 way
MP720856
MP720857
2ns/div - 1000s/div, Stepping in
the 1-2-5 way
Time base
accuracy
±100 ppm
Record length
Single channel: up to 8K
Dual channel: 4K
Vertical
Sensitivity
(Volt/div) range
10 mV/div～10 V/div
Displacement
range
±6 div
Analog bandwidth
MP720781;MP720780
40 MHz
MP720783;MP720782
70 MHz
MP720856;MP720857
100 MHz
Single bandwidth
Full bandwidth
Low frequency
response
(AC coupling, -
3dB)
≥10 Hz
Rise time
(typical on BNC)
MP720781;MP720780
≤ 8 ns
MP720783;MP720782 ≤ 5 ns
MP720856;MP720857 ≤ 3.5 ns
DC gain accuracy 3%
Cursor ΔV, ΔT, ΔT&ΔV between
Measuremen
t
Automatic
Period, Frequency, Mean, PK-PK,
Max, Min, Amplitude
Source CH1, CH2
Trigging R
Type
Edge
Coupling
DC, AC
Trigger type
Auto, normal, single
Trigger electrical
level range
±4 divs from the center of the screen
