37
[6] Specifications are for amplitude of sine wave input > 0.5% of range. For inputs from 1% to 5% of range,
add 0.1% of range extra error.
[7] Specifications are for 2–wire ohms using the relative operation of math. Without relative operation, add
±0.20 Ω additional error in 2-wire ohms function.
[8] Except for special marks, when frequency ≤ 10M Hz, the specification is applicable to >1V AC input
voltage, when frequency > 10 MHz, the specification is applicable to >3V AC input voltage.
[9] Specifications are for using the relative operation of math. Using of non-film capacitor may generate
additional errors. Specifications are for from 5% to 110% on ranges.
General Specifications
Display Screen
3.7-inch TFT LCD with resolution 480*320
Operating
Environment
Full
temperature
from 0℃ to 50℃, 80% RH and 40℃, non-condensing
Storage Temperature: -20℃ to 70℃
Remote Interface
USB Device
Programmer
Language
Standard SCPI, compatible with commands of main stream multimeters
Warm Up Time
30 minutes
Dimension (W×H×D)
200 x 86.5 x 64 (mm)
Weight
0.45 kg
