ALBI AQUA - Commissioning Instructions
1. Remove the top cover by releasing the two lid securing screws located at the top-
rear of the unit (see Fig.2, circled red)…
2. Removetheredbathllcap,andcarefullyllthewaterbathwithcleancoldwater,
viaafunnel,untilatrickleofwaterisseenexitingtheoverowtubeintothedriptray
(seeFigs.3&4)…Thellvolumeisapproximately10litres.
3. The model shown in Fig.4 is the variant requiring an insulated mini-python and
tower connection. The mini-python should contain a line for carbonated water,
alineforstillwater,andapairofowandreturnbathwaterrecirculationlines,
bundled and taped together along their length. The bundle must be insulated with
closed-cell tube insulation. The python can be MAX 5 metres long, including a MAX
lift of 1.5 metres. Line connections are shown in Fig.5…
Fig.2
Fig.3 Fig.4
Bath ll cap
Overow
tube
32
