26
4. Specication
WingStabi LED codes:
· ashing green/red: rmware update
· ashing green: system startup
· ashing red: error:
- No conguration available
- No RC signal
- Stick moves when the WingStabi is switched on
- Model moves when switched on
- Critical error, hardware failure
· green continuous: everything OK,
ailerons twitch slightly signaling
they are ready
WINGSTABI 12/16
Channels 12 or 16
Weight excl. integral receiver 92 g
Weight incl. integral receiver 100 g
Dimensions
(L x W x H)
approx. 74 x 58 x 16 mm
Operating voltage
6.0 to 9.0 V, Power supply only permitted
by using the two battery terminals.
Power supply 5 NiXX cells, 2S LiPo/Lilo/LiFe
Operating temperature range –20°C to +55°C
WINGSTABI RX-12/16-DR M-LINK
Receiving system M-Link 2.4 GHz
Servo channel count 12/16
Aerial length 2 x 37 cm
