DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 111
KUBOTA Z482-EB/E2B/E3B ENG. — PISTON AND CRANKSHAFT ASSY.
PISTON AND CRANKSHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1685121112 PISTON STD ...................................................2................Z482-EB AND Z482-E2B
010 1685121114 PISTON STD ...................................................2................Z482-E3B
010 1685121900 PISTON +0.25MM ..............................................2................Z482-EB AND Z482-E2B
010 1685121903 PISTON +0.25MM ..............................................2................Z482-E3B
020 1685321050 ASSY. PISTON RING STD 2
020 1685321090 ASSY. PISTON RING +0.25MM 2
030 1685121310 PIN, PISTON 2
040 1526121330 AIR CLIP, PISTON PIN 4
050 1685122010 CONNECTING ROD ASSY., Z482-EB...............2................INCLUDES ITEMS W/%
050 1685122015 CONN. ROD ASSY. Z482-E2B/E3B ...................2................INCLUDES ITEMS W/+
060% 1685121980 BUSH, PISTON PIN ...........................................2................Z482-EB
060+ 1685121982 BUSH, PISTON PIN ...........................................2................Z482-E2B AND Z482-E3B
070%+ 1685122140 BOLT, CONNECTING ROD 4
080%+ 1685122320 METAL, CRANKPIN M STD SET 2
080 1586122970 METAL, CRANKPIN -0.20MM SET 2
080 1586122980 METAL, CRANKPIN -0.40MM SET 2
090 1685323030 CRANKSHAFT ASSY. ........................................1................INCLUDES ITEMS W/#
100# 0771503207 BALL 2
110# 1921523280 SLEEVE, CRANKSHAFT 1
120 1584124110 GEAR, CRANK 1
130 0571200515 KEY, FEATHER 1
140 1586123470 METAL, CRANKSHAFT STD 1
140 1586123910 METAL, CRANKSHAFT -0.20MM 1
140 1586123920 METAL, CRANKSHAFT -0.40MM 1
150 1686123480 METAL, CRANKSHAFT M STD SET 1
150 1569423930 METAL, CRANKSHAFT -0.20MMSET 1
150 1569423940 METAL, CRANKSHAFT -0.40MMSET 1
160 1686123490 METAL, CRANKSHAFT STD SET 1
160 1586123860 METAL, CRANKSHAFT -0.20MM SET 1
160 1586123870 METAL, CRANKSHAFT -0.40MM SET 1
170 1526123530 METAL, SIDE STD 2
170 1526123950 METAL, SIDE +0.20MM 2
170 1526123960 METAL, SIDE +0.40MM 2
180 1526123540 METAL, SIDE STD 2
180 1526123970 METAL, SIDE +0.20MM 2
180 1526123980 METAL, SIDE +0.40MM 2
190 1584123250 COLLAR, CRANKSHAFT 1
200 1588123310 SLINGER, OIL 1
210 0481416220 O-RING 1
