DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 67
CONTROL PANEL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 A5225000303 CONTROL PANEL 1
1 A5511302402 CONTROL PANEL .............................................1................DA7000SSA
2 0021805020 MACHINE SCREW 4
3 0601800258 AC VOLTMETER, 120/240 1
4 0207003000 HEX NUT 2
5 0601807456 CIRCUIT BREAKER, KM52 265V 25A 1
6 4341817004 BRACKET CIRCUIT BREAKER 1
7 0021004016 MACHINE SCREW 2
8 0601830771 IDLE CONTROL SWITCH 1
9 1628663602 STARTER SWITCH ...........................................1................REPLACES 0602100077
9A 3741055150 IGNITION, KEY
10 0601810523 INDICATOR ASSY. 1
10A 0601810830 BULB 4
11 0601800682 HOUR METER 820114 1
12 0027403512 MACHINE SCREW 2
12A 0030003500 HEX NUT 2
13 0601811034 RECEPTACLE CS6369 125 250V 50A ..............1................REPLACES 0601812566
14 0601812529 RECEPTACLE, L14- 30R 125V 30A 1
15 0601811031 RECEPTACLE, L5-30R 125V 30A .....................1................REPLACES 0601811035
16 0601812597 RECEPTACLE, 5-20R 120V 20A ......................1................REPLACES 0601812598
17 0021004010 MACHINE SCREW 8
17A 0030004000 HEX NUT ...........................................................8................REPLACES 0207004000
18 0601806420 CIRCUIT PROTECTOR, AC 250V 20A 1
19 0027103005 MACHINE SCREW 2
20 0601815109 GROUND TERMINAL 1
