DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 79
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 D2365000013 FUEL TANK 1
1A 0810105800 CAP, FUEL TANK 1
1B 0810105900 FUEL FILTER 1
2 0602125033 FUEL GAUGE 1
3 D2365200004 TANK BAND 2
4 0805003414 PAD, TANK BANK 4
5 0016906016 HEX. HEAD BOLT 2
6 0207308000 HEX. NUT 2
7 D1490600104 RUBBER SEAL 1
8 1615511204 RUBBER SEAL 1
8 B9312400004A RUBBER SEAL .................................. 1 ..................DA7000SSA
9 7812014003 DRAIN JOINT 1
10 0802011104 PLUG 1
11 0150000018 O-RING A P18 1
12 0016906016 HEX. HEAD BOLT 2
13 0199900670 DRAIN HOSE 1
14 0605515094 HOSE BAND F-12 2
15 1553143010 FUEL FILTER ASSY. .......................... 1 ..................REPLACES 0602042460 AND 1553143012
15A 1523143560 ELEMENT, FUEL FILTER .................. 1 ..................REPLACES 0602042171 AND 1523143563
16 D2368700004 BRACKET, FUEL FILTER 1
17 0016906016 HEX. HEAD BOLT 2
18 0016908065 HEX. HEAD BOLT 1
19 0966180240 SUCTION HOSE ................................ 1 .................. REPLACES 0605513158
20 0966180400 SUCTION HOSE ................................ 1 .................. REPLACES 0605513101
21 0966140320 RETURN HOSE ................................. 1 .................. REPLACES 0605514101
22 0966140240 RETURN HOSE ................................. 1 .................. REPLACES 0605514102
23 1491142750 HOSE BAND ...................................... 4 .................. REPLACES 0605515070
24 1024442320 HOSE BAND ...................................... 4 .................. REPLACES 0605515072
To Next Page
