DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 71
ENGINE AND RADIATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 A5925200004 ENGINE, Z482EB ........................ 1 ........DA7000SS
1 A5924200004 ENGINE, Z482E2BDGDE2 .......... 1 ........DA7000SS
1 A5924200094 ENGINE, Z482E3BDGDE2 .......... 1 ........DA7000SSA
1A 1980572531 FAN BELT ..................................... 1 ........REPLACES P/N 0602011477
1-1 7000015241 CARTRIDGE OIL FILTER ............ 1 ........REPLACES P/N's 1584132430 AND 0602041271
1-1 1585332435 CARTRIDGE OIL FILTER ............ 1 ........Z482-E3B ENGINE
2 8745112003 ENGINE FOOT 2
3 0012410020 HEX HEAD BOLT 8
4 7085419004 RUBBER SUSPENSION 2
5 0207010000 HEX NUT 2
6 0602012750 RADIATOR ................................... 1 ........INCLUDES ITEM W/#
6 0602012795 RADIATOR ................................... 1 ........INCLUDES ITEM W/% DA7000SSA
6-1# 0602011074 CAP RADIATOR 1
6-1% 0602011079 CAP RADIATOR ........................... 1 ........DA7000SSA
7 8702014004 INSULATOR ................................. 2 ........DA7000SS-DA7000SSW ONLY
8 0605000460 RUBBER MOUNT 2
9 D2312500103 RADIATOR HOSE 1
10 D2312500003 RADIATOR HOSE 1
11 0605515111 HOSE BAND, Ø34 2
11 0605515134 HOSE BAND HS-16 ..................... 2 ........DA7000SSA
12 0605515003 HOSE BAND, Ø30 2
13 1556211010 FILTER AIR CLEANER ASSY. ..... 1 ........REPLACES P/N 0602046265
13A 7000011221 ELEMENT AIR CLEANER ........... 1 ........REPLACES P/N's 0602046374, 1556211081
14 3415013960 BAND 1
14A 0222600340 RUBBER CUSHION 1
15 0016908030 HEX HEAD BOLT 1
16 0207008000 HEX NUT 1
17 8742031004 BRACKET AIR CLEANER 1
18 0016908020 HEX HEAD BOLT 2
19 0016906016 HEX HEAD BOLT 2
20 8742032003 HOSE AIR CLEANER 1
21 1612036203 HOSE AIR CLEANER 1
22 0605515006 HOSE BAND, Ø50 1
23 0605515021 HOSE BAND, Ø55 2
24 1622014103 DRAIN JOINT WATER 1
25 1502025103 DRAIN JOINT OIL 1
NOTICE
For Tier II white units air cleaner assy., See Kubota
engine section in this manual.
