DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 121
KUBOTA Z482-EB/E2B/E3B ENG. — INJECTION PUMP ASSY.
INJECTION PUMP ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1600151010 PUMP ASSY., INJECTION ................................1................INCLUDES ITEMS W/%
020 1600152090 SHIM, INJECTION PUMP, 20 MM 1
020 1600152110 SHIM, INJECTION PUMP, 25 MM 1
020 1600152120 SHIM, INJECTION PUMP, 30 MM 1
020 1G68952160 SHIM, INJECTION PUMP, 35 MM .....................1................Z482-E3B ONLY
020 1G68952200 SHIM, INJECTION PUMP, 175 MM ...................1................Z482-E3B ONLY
030 0131110620 BOLT, HEX-SOC-HD 3
040 1584191500 STUD 1
050 1584192320 NUT, CAP 1
060 0451260060 WASHER, LOCK 4
070 1584195680 JOINT, EYE 1
080 1526342010 ASSY. PIPE, FUEL .............................................1................INCLUDES ITEMS W/#
090# 1491142750 CLIP, PIPE 2
095# 6659154250 SPRING, PIPE PROTECT 1
100% 1584151320 SCREW HOLLOW .............................................1................Z482-E2B /Z482-E3B ONLY
110% 1584196650 GASKET ............................................................2................Z482-E2B AND Z482-E3B ONLY
120% 1584151350 SCREW ..............................................................1................Z482-E2B AND Z482-E3B ONLY
130% 1584196660 GASKET ............................................................1................Z482-E2B AND Z482-E3B ONLY
