DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 125
KUBOTA Z482-EB/E2B/E3B ENG. — SPEED CONTROL PLATE ASSY.
SPEED CONTROL PLATE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1584157110 PLATE, SPEED CONTROL ...............................1................Z482-EB
010% 1584157112 PLATE, SPEED CONTROL ...............................1................Z482-E2B AND Z482-E3B
020 1584157212 GASKET, CONTROL PLATE 1
030 0102350618 BOLT 2
040 0105350618 BOLT ..................................................................2................Z482-EB AND Z482-E2B
040 1687191050 BOLT ..................................................................2................Z482-E3B
050 1560196650 GASKET ............................................................2................Z482-EB AND Z482-E2B
060 1584156110 LEVER, GOVERNOR ........................................1................Z482-EB
060% 1584156112 LEVER, GOVERNOR ........................................1................Z482-E2B AND Z482-E3B
070 1584157240 COLLAR .............................................................1................Z482-EB
070 1928057240 COLLAR .............................................................1................Z482-E2B AND Z482-E3B
080% 0481410160 O-RING 1
090% 1666757150 LEVER, SPEED CONTROL 1
100 1584192010 NUT, SPEED CONTROL ...................................2................Z482-EB
100% 1686692010 NUT, SPEED CONTROL ...................................2................Z482-E2B AND Z482-E3B
110 1687857740 SHAFT, LEVER ..................................................1................Z482-EB
110% 1687857742 SHAFT, LEVER ..................................................1................Z482-E2B AND Z482-E3B
120 1685157720 LEVER, ENGINE STOP .....................................1................Z482-EB
120% 1685157724 LEVER, ENGINE STOP .....................................1................Z482-E2B AND Z482-E3B
130 0541100318 PIN, SPRING .....................................................1................Z482-EB
130% 0541100314 PIN, SPRING .....................................................1................Z482-E2B AND Z482-E3B
140% 0481410070 O-RING 1
150% 1687857920 SPRING, RETURN 1
160 1686657300 CAP ....................................................................1................Z482-EB
160% 1686657302 CAP ....................................................................1................Z482-E2B AND Z482-E3B
170% 1756157013 COMP. PLATE, SPEED CO. ...............................1................INCLUDES ITEMS W%
180% 1920291010 BOLT ..................................................................2................Z482-E3B ONLY
190% 1920291010 BOLT ..................................................................3................Z482-E3B ONLY
200% 0205650060 NUT ....................................................................3................Z482-E3B ONLY
To Next Page
