DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 133
KUBOTA Z482-EB/E2B/E3B ENGINE — FUEL FILTER ASSY.
FUEL FILTER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1553143010 FILTER, FUEL ASSY. .........................................1................INCLUDES ITEMS W/$
.............................................................................................REPLACES P/N 1553143012
020$ 1553143110 COMP. BODY, COCK .........................................1................INCLUDES ITEMS W/#
030$# 1430143522 LEVER, COCK 1
040 $# 1430143820 SPRING, VALVE 1
050$# 1430143830 SCREW, SET 1
060$# 1430143840 O-RING, LEVER 1
070$ 1539343100 CUP ASSY., FILTER ..........................................1................INCLUDES ITEMS W/%
080$% 1539343580 CUP, FILTER 1
090*% 1687388430 LABEL, FUEL 1
100$ 1430143590 RING, RETAINING 1
110$ 1430143650 O-RING, FILTER CUP .......................................1................Z482-EB AND Z482-E2B
110$ 0481600390 O-RING, FILTER CUP .......................................1................Z482-E3B ONLY
120$ 1523143560 ELEMENT, FUEL FILTER ..................................1................Z482-EB AND Z482-E2B
120$ 1T02143560 ELEMENT, FUEL FILTER ..................................1................Z482-E3B
130$ 1430143570 O-RING, FILTER
