DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 147
KUBOTA Z482-EB/E2B/E3B ENGINE — WATER FLANGE & THERM. ASSY.
WATER FLANGE AND THERMOSTAT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1687572700 COMP. FLANGE, WATER, Z482-EB ..................1................INCLUDES ITEMS W/%
010 1687572704 COMP. FLANGE, WATER, Z482-E2B/E3B ........1................INCLUDES ITEMS W/#
020%# 1624173370 PIPE, WATER RETURN 1
030 1584172922 GASKET, WATER FLANGE ...............................1................Z482-EB
030 1584172923 GASKET, WATER FLANGE ...............................1................Z482-E2B AND Z482-E3B
040 0102350616 BOLT 2
050 0102360650 BOLT 4
060 1685173350 PIPE, WATER RETURN 1
070 1624173360 BAND, PIPE 2
080 1553173010 THERMOSTAT ASSY. 1
090 1584173260 COVER, THERMOSTAT 1
100 1685173270 GASKET, THERMOSTAT 1
110 0102350622 BOLT 2
120 1554383040 SWITCH, THERMOMETER ...............................1................Z482-EB
120 1753883040 SWITCH, THERMOMETER ...............................1................Z482-E2B AND Z482-E3B
