DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 65
GENERATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 A5110100003 ROTOR ASSY. ...................................................1................INCLUDES ITEMS W/#
1-1# A5116000103 FIELD ASSY. 1
1-2# 7871025004 RECTIFIER ASSY. 2
1-3# 042006304 BEARING 6304 DOU .........................................1................REPLACES 0071206304
1-4# A5113100002 FAN 1
1-5# 0171707033 KEY 1
1-6# 1991072004 SET WASHER FAN 1
1-7# 0012308020 HEX HEAD BOLT 1
2 011208025 HEX HEAD BOLT ...............................................5................REPLACES 0012308025
3 A515510002 END BRACKET 1
4 A5136000103 ARMATURE ASSY. 1
5 A6155000002C END BRACKET .................................................1................REPLACES A6155000002
6 7871329514 GROMMET 1
7 7901316004 SET BOLT 4
8 0040008000 WASHER, LOCK 4
9 031108160 WASHER, FLAT .................................................4................REPLACES 0041206000
10 A6155400104C COVER ..............................................................1................REPLACES A6155400104
11 0027106012 MACHINE SCREW 3
11 0027105012 MACHINE SCREW ............................................3................DA7000SSA
12 0012308020 HEX HEAD BOLT 6
13 0805084704 RUBBER SUSPENSION 2
14 020108060 HEX NUT ...........................................................2................REPLACES 0207006000
14A 0801086104 WASHER, FLAT 2
