DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 97
KUBOTA Z482-EB/E2B/E3B ENGINE — GEAR CASE ASSY.
GEAR CASE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
010 1687504024 COMP. CASE, GEAR, Z482EB, Z482E2B .........1................INCLUDES ITEMS W/#
010 1E05104024 COMP. CASE, GEAR, Z482E3B ........................1................INCLUDES ITEMS W/%
020#% 1685196010 PLUG .................................................................2................Z482EB
020#% 1552196030 PLUG .................................................................2................Z482-E2B AND Z482-E3B
030#% 1584156280 PIN, START SPRING 1
040 0481406130 O-RING ..............................................................3................Z482-EB AND Z482-E2B
050 1586204132 GASKET, GEAR CASE .....................................1................Z482-EB AND Z482-E2B
050 1586204130 GASKET, GEAR CASE .....................................1................Z482-E3B
060 0102350618 BOLT 1
070 0102360650 BOLT 8
080 1584191010 BOLT 5
090 0102350670 BOLT ..................................................................1................Z482EB
090 0102360670 BOLT ..................................................................1................Z482E2B AND Z482-E3B
100 0102350675 BOLT 1
130 1587704140 SEAL, OIL 1
150 1685136950 SPRING 1
160 1584136930 SEAT, VALVE 1
170 0771503211 BALL 1
180 1584633110 FLANGE, OIL FILLER 1
190 1381133140 PLUG, OIL FILLER 1
200 0481106230 O-RING 1
210 1946188132 GASKET, H/M GEAR CASE 1
220 1522188210 STUD 3
230 0205650060 NUT 3
240 0451260060 WASHER, LOCK 3
