DA7000 SERIES GENERATORS • OPERATION AND PARTS MANUAL — REV. #5 (01/20/11) — PAGE 99
KUBOTA Z482-EB/E2B/E3B ENGINE — HEAD COVER ASSY.
HEAD COVER ASSY. (Z482-EB)
NO. PART NO. PART NAME QTY. REMARKS
010 1588105550 JOINT, BREATHER PIPE 1
020 1584105140 PLATE, BREATHER ELEMENT 1
030 1584105150 PLATE, BREATHER ELEMENT 1
040 1584105670 ELEMENT, BREATHER 1
050 1584105370 OIL SHIELD, BREATHER 1
060 1686193310 SCREW 2
070 1584705512 PIPE, BREATHER 1
080 1584105590 CLAMP, PIPE 1
090 0211450080 NUT 1
100 0401360080 WASHER, FLATT 2
110 1685114512 COVER, CYLINDER HEAD ...............................1................Z482-EB
120 1685114522 GASKET, HEAD COVER 1
130 1584114620 NUT, CAP 2
140 1560196650 GASKET 2
150 1585233140 PLUG, OIL FILLER 1
160 0481150300 O-RING 1
