PAGE 14 — EM120 HYD. PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #1 (09/09/19)
GENERAL INFORMATION
APPLICATION
This mixer is only intended for the mixing of plaster and
mortar. The mixer must be used for its intended purpose
and is not suitable for the mixing of flammable or explosive
substances. The mixer must not be used in an explosive
atmosphere.
The drum capacity of this hydraulic mixer is 12.0 cu. ft.
(340 liters) with a batch capacity between 3-1/2 and 4-1/2
bags. Mixer is shipped completely assembled and has been
factory tested and is ready for use.
POWER PLANTS
Mixer is powered by a 11.7 HP, air-cooled, 4-stroke gasoline
engine. Refer to Table 2 for specific engine details.
HARDWARE
Check all hardware on the mixer before starting. Periodically
inspect all hardware. Loose hardware can contribute
to early component failure and poor performance. Use
Table 4 as general guideline when the torqueing of mixer
hardware is required. Remember to keep all mixer hardware
components tight.
Table 4. Hardware Torque Recommendations
Hardware Diameter Torque (ft-lbs)
5/16-inch x 18 14
3/8-inch x 16 24
3/8-inch x 24 37
1/2-inch x 13 39
1/2-inch x 13 (Grade 8) 90
ENGINE MAINTENANCE
For basic engine maintenance, refer to the engine
maintenance section in this manual. For more detailed
engine maintenance, refer to the Honda Engine Owner's
manual furnished with the engine.
