MULTIQUIP EM120 - Inspection

PAGE 20 — EM120 HYD. PLASTER/MORTAR MIXER • OPERATION AND PARTS MANUAL — REV. #1 (09/09/19)
STEEL DRUM
SIDE PADDLE BLADE
P DNE EDALB ELDDA
ROTATION
TOR TA OI N
PADDLE BLADE IS TOO
TIGHT AGAINST DRUM
SIDE WALLS.
PADDLE BLADE IS TOO
TIGHT AGAINST DRUM
SIDE WALLS.
DRUM END AND SIDE WALLS
INCORRECT
INCORRECT
CORRECT
CORRECT
CENTER ENGINE
END CAST PADDLE
ENGINE END
ADDLE
CAST P
CENTER TOW END
CAST PADDLE
ENGINE END
CAST PADDLE
DRUM END
DRUM SIDE
INSPECTION
Figure 5. Paddle Blade Adjustment
Adjust paddles as shown in Figure 5.
