EM120 HYD. PLASTER/MORTAR MIXER• OPERATION AND PARTS MANUAL — REV. #1 (09/09/19) — PAGE 25
Figure 21. Drum (Dump Position)
2. Push hydraulic dump lever inward to place drum back
in the upright position.
WARNING
When rotating the
mixing drum from the
dump position to the
upright position, keep
hands clear of safety
grate. The possibility
exists of hands or
fingers being crushed.
OPERATION
STOPPING THE MIXER
1. Push the main start/stop switch (Figure 22) inward to
stop the engine.
Figure 22. Start/Stop Button (Stop Position)
2. Place fuel shut-off lever in the OFF position.
3. Clean drum of all debris and foreign matter.
