EM120 HYD. PLASTER/MORTAR MIXER• OPERATION AND PARTS MANUAL — REV. #1 (09/09/19) — PAGE 43
NO. PART NO. PART NAME QTY. REMARKS
2 492584 NUT, LOCK 1/2" DIA. NC 8
3 EM200294B PADDLE ARM CENTER (TOW END) 1
5 EM200292 INSERT, PADDLE ARM .....................................8................REPLACES P/N 200292
6 EM200296B PADDLE ARM, ENGINE END 1
7 6109170 WASHER, FLAT 1/2" ..........................................8................REPLACES P/N 504322
8 EM200297 U-BOLT ..............................................................4................REPLACES P/N 200297
9 EM200295B PADDLE ARM CENTER (ENGINE END) 1
10$ 2105162 SCREW HHC ....................................................14...............REPLACES P/N 492367
11$ EM923023 WASHER, FLAT 5/16" .......................................28...............REPLACES P/N 49259
12$ EM200212 SIDE WIPER, RUBBER 4
13$ EM203432 SIDE SCRAPER BLADE 4
14$ 2105164 NUT HEX 5/16" DIA. NC ...................................14...............REPLACES P/N 492553
15$ EM923343 WASHER, LOCK 5/16" .....................................14...............REPLACES P/N 492623
16 EM200293B PADDLE ARM, TOW END 1
17 EM203433 END SCRAPER BLADE 2
18 EM200213 END WIPER, RUBBER 2
19 EM200863 KIT, RUBBER BLADES, SCRAPERS & HDW. ...1................INCLUDES ITEMS W/$
PADDLE BLADES ASSY.
