EM120 HYD. PLASTER/MORTAR MIXER• OPERATION AND PARTS MANUAL — REV. #1 (09/09/19) — PAGE 45
DRUM AND SHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 521678 DRUM AND SHAFT ASSY. ................................1................INCLUDES ITEMS W/$
2$ 925191 PIN, COTTER 3/16" 1
3$ 6109170 WASHER, FLAT 1/2" DIA. ..................................3................REPLACES P/N 49260
4$ 13276 BAR, GRATE OPENING 1
5$ EM203449 DRUM GRILL 1
6$ EM924015 PIN, COTTER ....................................................2................REPLACES P/N 505070
7$ 492584 NUT, NYLOC 1/2" DIA NC 1
8$ 6109170 WASHER, FLAT 1/2" DIA. ..................................1................REPLACES P/N 492600
9$ EM963692 BOLT, 1/2"UNC X 1-1/2" ....................................1................REPLACES P/N 492394
10 521676 DRUM 12. CU. FT ..............................................1................DRUM ONLY
