EM120 HYD. PLASTER/MORTAR MIXER• OPERATION AND PARTS MANUAL — REV. #1 (09/09/19) — PAGE 47
PADDLE SHAFT ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 3249 CAP, DUST 1
2 521674 BRACKET, FRONT 1
3 EM703 SCREW, ALLEN 3/8" .........................................4................REPLACES P/N 492470
4 EM200018 COLLAR, PADDLE SHAFT 2
5 492396 BOLT 1/2" NC X 2" G5 4
6 491008 GREASE CAP FITTING 2
7 EM916019 FITTING GREASE .............................................2................REPLACES P/N 491705
8 EM902153 BEARING ...........................................................2................REPLACES P/N 902153
9 EM969012 NUT, NYLOC 3/8" ..............................................8................REPLACES P/N 505066
10 EM201648 DRUM HEAD WELDMENT 2
11 EM200287 ADJUSTING NUT ..............................................4................REPLACES P/N 200287
12 0401450160 WASHER, FLAT 5/8" ..........................................4................REPLACES P/N 492602
13 507844 SPRING COMPRESSOR 4
14 EM200288 PLATE, PACKING GLAND PRESSURE 2
16 EM200301 RING, SHAFT PACKING 12
15 EM200285 GLAND, PACKING, HALF 4
16 EM200303 FOLLOWER, PACKING RING 2
18 EM200286 BOLT, CARRAGE ...............................................4................REPLACES P/N 505065
19 17985-008 BOLT, CARRIAGE ..............................................8................REPLACES P/N 505064
20 521675 PADDLE SHAFT 1
21 521673 BRACKET, REAR 1
22 EM502727 KEY, SQUARE 5/16 X 1-3/8" 1
23 514235 COUPLING HYDRAULIC MOTOR 1
24 492468 SCREW SET 5/16" 2
25 511526 SCREW, HHCS 1" NC X 8 1
26 13286 SPACER, LOWER DUMP CYLINDER 1
27 511495 NUT, LOCK 1" NC 1
28 EM963610 CAP SCREW .....................................................1................REPLACES P/N 492375
29 520957 WASHER, 3/8" FLAT 1
30 0166 A WASHER LOCK 3/8" DIA. .................................1................REPLACES P/N 492624
31 492584 NUT, NYLOC 1/2" DIA. NC 4
32 EM621 WASHER, 1/2" SPECIAL ...................................4................REPLACES P/N 621
