EM120 HYD. PLASTER/MORTAR MIXER• OPERATION AND PARTS MANUAL — REV. #1 (09/09/19) — PAGE 49
HYDRAULIC ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 0166 A WASHER LOCK 3/8" DIA. .................................4................REPLACES P/N 492624
4 503117 BOLT 3/8" NC X 3" G5 3
6 13198 HOSE, ASM, DUMP CYL, 36" 2
8 13212 GROMMET, 1-1/4" ID 1
10 492584 NUT, NYLOC 1/2" DIA. NC 8
11 804032 BRACKET 1
12 492395 BOLT, 1/2"NC X 1-3/4" G5 4
14 515251 SPACER 3
16 EM34585 DIRECTIONAL CONTROL VALVE 1
18 13196 HOSE, PUMP OUTPUT, 21" 1
19 511845 FITTING 2
20 13210 STRAINER, IN LINE 1
21 515219 FITTING, 90° 1
22 3327 CYLINDER, DUMP 1
24 EM25459 ELBOW 3/4"-90° 1
25 511847 FITTING 1
26 3369 FITTING 2
28 13219 FITTING, 90° 1
30 3220 FITTING, STR 12BARB X 3/4MP 2
32 13243 HOSE, MOTOR, 17", W/90° FITTING 1
33 510263 FITTING, 90° STRAIGHT ELBOW 1
34 13225 HANDLE, DRIVE/DUMP VALVE CONTROL 2
35 492356 BOLT 1/4" X 3/4" 2
36 2101402 WASHER, LOCK 1/4" DIA. ................................2................REPLACES P/N 492622
40 13380 HOSE, 3/4"ID X 18-1/2 1
42 492396 BOLT, 1/2"NC X 2" 4
44 16587 FITTING .............................................................2................REPLACES P/N 3314
46 3322 FITTING, 90° 1
48 34570 MOTOR, HYDRAULIC 1
50 506207 CLAMP, HOSE 4
52 18052 OIL, SIGHT GAUGE 1
53 511691 FITTING, STR 1
54 3353 CAP, FILLER/BREATHER 1
56 3365 FITTING, STR 3
58 3367 FITTING, 90° 2
61 511847 FITTING, STR 1
62 3462 HOSE, .75 ID, 16.5 LONG 1
64 8051 FILTER, HYDRAULIC OIL 1
66 506094 PLUG 1/2"NPT GALVANIZED 1
70 804371 CLAMP, 1-1/4" 2
71 DULT100078J NUT M6, NYLOC G8 2
90 3407 KNOB 2
92 13242 HOSE W/90° FITTING 1
