EM120 HYD. PLASTER/MORTAR MIXER• OPERATION AND PARTS MANUAL — REV. #1 (09/09/19) — PAGE 51
FRAME ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 13365 CHASSIS ASSY. 1
2 501078 CHAIN SET 1
3 EM963692 BOLT 1/2"UNC X 1-1/2" .....................................4................REPLACES P/N 492394
4 3018 SPRING, LEAF 2
5 507444 WASHER, FLAT 3/4" 2
6 492534 NUT, CASTLE 3/4" 2
7 EM924008 PIN, COTTER 1/8" X 1-1/2" ...............................2................REPLACES P/N 491688
8 516477 WHEEL/TIRE ASSY. 2
9 29194 LUG NUT 10
10 3469 DUST CAP 2
11 504708 WASHER, FLAT 3/4" 2
12 EM941277 HUB COMPLETE, 5 LUGS 2
13 511699 AXLE 1
14 3028 U-BOLT, AXLE 2
15 492584 NUT LOCK 1/2" DIA. 10
16 3076 SPRING, AXLE 2
17 3043 BOLT 1/2" X 6" G5 .............................................2................REPLACES P/N 510721
18 HBC-1 TWO BAR (BALL HITCH 2-IN.) .........................1................CONTACT SALES
19 HLC-1 TOW BAR (LOOP) .............................................1................CONTACT SALES
20 HPC-1 TOW BAR (1" PIN) .............................................1................CONTACT SALES
