Multitech Conduit Series - V2.1 Power Draw

SPECIFICATIONS AND RELATED INFORMATION
Conduit
®
Base Station IP67 Getting Started Guide for Versions 1.5 and 2.1 19
1
Maximum Power: The continuous current during maximum data rate with the radio transmitter at
maximum power.
2
TX Pulse: The average peak current during a GSM850 transmission burst period or HSDPA connection. The
transmission burst duration for GSM850 can vary, depending on what transmission scheme is being
deployed.
3
Inrush Charge: The total inrush charge at power on.
V2.1 Power Draw
Power draw for model MTCDTIP-LAT1-275L-915:
Voltage Radio Protocol Sleep Mode
Current (If
Applicable
Cellular Call
Box
Connection No
Data
IP Connection
to Cellular Call
Box with Data:
(AVG)
Measure
Current at
Max Power
TX Pulse
(AVG)
Amplitude
Current for
GSM850 or
Peak Current
for HSDPA
Total Inrush
Charge
Measured in
Millicoulombs
56.0 Volts LTE NA 154 mA 246 mA 312 mA 4.93 mC
42.0 Volts
(Safety Testing
Limit)
LTE NA 207 mA 332 mA 404 mA 4.4 mC
Tx Pulse: The average peak current during a GSM850 transmission burst period or HSDPA connection. The
transmission burst duration for GSM850 can vary depending on what transmission scheme is being deployed (GPRS
Class 8, Class 10, GSM, etc.).
Max Power: The continuous current during maximum data rate with the radio transmitter at maximum power.
Inrush Charge: The total inrush charge at power on.
