SETTING UP HARDWARE
MultiConnect
®
Conduit
TM
AP MTCAP User Guide for Europe 19
Chapter 5 – Setting Up Hardware
Installing a SIM Card
If you have a cellular device with a SIM slot, you'll need a micro SIM card from your network provider.
To install the SIM card:
With the contact side facing down, align the notched edge as shown on the following image and slide the
SIM card completely into the SIM holder.
Removing a SIM Card
To remove the SIM card, push the SIM card in. The device ejects the SIM card.
Cabling the Device
To cable the device:
1. Connect the Ethernet cable to the Ethernet port on the device and to your computer.
2. Connect the power supply to the MTCAP's power jack and plug it into an electrical outlet. When the
operating system is fully loaded, the STATUS LED blinks.
Once your device is cabled, follow the Getting Started chapter for your device:
For models ending with -001L , go to Getting Started with mLinux
