LTE SPECIFICATIONS
MultiConnect
®
rCell 100 MTR-LTE User Guide 13
Category MTR-LAT1 (North America
AT&T, T-Mobile)
MTR-LVW2 (North
America Verizon)
MTR-LEU1 (EU Carriers)
Cellular packet data Up to 100 Mbps downlink (Theoretical maximum - actual performance may be
affected by multiple environmental factors.)
Up to 50 Mbps uplink (See above note.)
Diversity/MIMO Rx Diversity and MIMO DL 2x2
SMS Point-to-Point messaging, Mobile terminated SMS, Mobile originated SMS
Connectors
Cellular Female SMA connector
GPS Female SMA connector
SIM Holder Mini-SIM standard 1.8 V
and 3 V
N/A Mini-SIM standard 1.8 V
and 3 V
eNet (LAN) RJ-45, 10/100 Base T
GPS Female SMA connector
RS-232 DCE 9-pin, female connector
Power 25 mm miniature locking power jack (screw on)
Power Requirements
1
Voltage 7 V to 32 V DC
Physical Description
Dimensions 4.17” x 3.0” x 1.15” (10.6cm x 7.6cm x 2.9cm)
Weight 0.51 lbs (0.231 Kg)
Chassis type Aluminum
Environment
Operating Temperature
2
-40° C to +80° C
Storage Temperature
2
-40° C to +85° C
Humidity Relative humidity 15% to 93% non-condensing
Certifications, Compliance, Warranty
Regulatory FCC Class B (U.S.), IC
(Canada)
FCC Class B (U.S.) CE Mark, RED (EU)
Safety UL60950-1, UL 201,
cUL60950-1
UL60950-1, UL 201 IEC60950-1(EU)
Network PTCRB, AT&T, T-Mobile Verizon (pending) Telstra, EU carriers
Quality Designed and built-in ISO 9001/13485 facilities
MIL-STD-810: High Temp, Low Temp, Cold Dwell, Random, and Sine vibration
SAE J1455: Random and Sine vibration
