SETTING UP CELLULAR FEATURES
44 MultiConnect
®
rCell 100 MTR-LTE User Guide
Unavailable Services in PPP-IP Passthrough and Serial Modem
Modes
In both PPP-IP Passthrough and Serial Modem modes, many rCell services described in this document are non-
configurable and therefore do not appear in the device configuration menu. If you choose one of these modes, all
sections between this and the next note on this subject are not available.
Configuring Wake Up On Call
This feature allows the router to wake up and initiate a cellular connection when there is an incoming call, SMS, or
LAN activity.
The Wake Up on Call function is not available for the LVW2 (even though you can access those settings in the
device software.)
1. Go to Cellular > Wake Up On Call to display the configurations.
2. Check the Wake Up On Call box.
3. Select a Wake Up setting. For wakeup methods, see Wake Up On Call Method Settings.
4. Click Submit.
5. To save your changes, click Save and Restart.
Note: This feature only defines when the device brings up its cellular link, not when the device takes it down.
See the Dial on Demand option on the Cellular Configuration page at Cellular > Cellular Configuration to
configure the criteria for bringing the cellular link down.
Wake Up On Call Method Settings
The triggers that wake up the router to re-establish the cellular link are:
On Ring:
Any incoming call will bring up the cellular link.
Enabled: Check to allow any incoming call to wake up the router.
Message: The expected response from the integrated cellular modem to an incoming call.
On Caller ID:
Only incoming calls in the caller ID list will bring up the cellular link.
Enabled: Check to allow a specific caller to wake up the router.
Caller ID: Field to specify a caller ID. Enter the ID then click Add to add the caller to the approved caller
ID trigger list.
On SMS (not available if you enabled SMS through SMS > General Configuration):
Only specific SMS messages will bring up the cellular link.
Enabled: Check to allow specific SMS messages to wake up the router.
Message: Field to specify the SMS message contents. Click Add to add the SMS message to the approved
SMS trigger list.
For Wake-Up-On-Call field descriptions, see Wake Up On Call General Configurations.
