CONFIGURING YOUR DEVICE
36 MultiConnect
®
rCell 100 MTR-LTE User Guide
3. In the Port field, type the port number on which the TCP server is listening for connections. The default is
5445. You can use up to five digits. Each digit itself must be between 0 and 9. Numbers above 65,535 are
illegal as the port identification fields are 16 bits long in the TCP header.
4. Enter Password and confirm Password.
5. Click Submit.
6. To save your changes, click Save and Restart.
Sending GPS information to a remote server
The Client Configuration allows the device to connect to a remote server using the IP and port information for
uploading GPS data.
1. To allow the device to connect, go to Setup > GPS Configuration > Client Configuration.
2. Check TCP/UDP Client.
3. From the Protocol drop-down list, select the protocol of the client (TCP or UDP).
4. In the Remote Host field, type the IP address of the remote host.
5. In the Port, field type the port number of the remote host.
6. If your remote host requests a password, type that password in the Password field. The password is sent
to the server in response.
7. Click Submit.
8. To save your changes, click Save and Restart.
Configuring NMEA Sentences
To configure the time interval, additional prefix or ID information, and which NMEA sentences that can be sent:
1. Go to Setup > GPS Configuration > NMEA Configuration and in the Interval field, type the amount of
time, in seconds, that passes before the NMEA information is sent. The default is 10 seconds. The range is
1 to 255 seconds.
2. You can further identify the router, also called a remote asset, that is collecting and sending the GPS
information. To do so:
Add ID: The ID is an unique remote asset identification string. The ID string can be any length up to 20
characters. The & and $ are invalid characters. The ID must follow the standard NMEA sentence structure.
Refer to the Universal IP AT Commands Reference Guide for sentence structure.
To add more information to the beginning of the ID, in the Add ID Prefix field, type the information.
3. You can select which NMEA sentence types you want to send. Check any combination of the available
options: GGA, GSA, GSV, GLL, RMC, and VTG.
SMTP Settings
The following table lists the configuration fields in the SMTP window.
Field Description
SMTP Configuration
Enabled Click to use the SMTP feature.
Server Enter the SMTP server address.
Port Enter the port number that the SMTP server uses.
