LTE SPECIFICATIONS
16 MultiConnect
®
rCell 100 MTR-LTE User Guide
Radio Protocol Sleep Mode
Current (If
Applicable)
(Amps)
Cellular Call Box
Connection No
Data (Amps)
Average Measured
Current (Amps) at
Maximum Power
TX Pulse (Avg)
Amplitude
Current (Amps) )
for GSM850 or
Peak Current for
HSDPA/LTE
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
LTE NA 0.181 0.487 0.580 0.118
20.0 Volts
EGSM 900Mhz NA 0.095 0.149 0.505 0.106
LTE NA 0.101 0.236 0.316 0.106
32.0 Volts
EGSM 900Mhz NA 0.063 0.097 0.300 0.281
LTE NA 0.069 0.153 0.228 0.281
MTR-LVW2-B08 Power Draw
Radio Protocol Sleep Mode
Current (If
Applicable)
(Amps)
Cellular Call Box
Connection No
Data (Amps)
Average Measured
Current (Amps) at
Maximum Power
TX Pulse (Avg)
Amplitude
Current (Amps) )
for GSM850 or
Peak Current for
HSDPA/LTE
Total Inrush
Charge
Measured in
Millicoulombs
(mC)
9.0 Volts
LTE NA 0.174 0.442 0.528 0.856
20.0 Volts
LTE NA 0.094 0.214 0.288 0.860
32.0 Volts
LTE NA 0.062 0.138 0.204 2.74
