Introduction 4
DryCool HD Operator and Maintenance Manual P00960167-1
1.4. Specifications
1.4.1. DryCool™ HD Dehumidifier Specifications
Model DRYCOOL™ HD
Electrical
115 / 60
Capacity
120 Pints/day @ 80° F / 60% RH
Operating Current
6.8 Amps/Power consumption at full load
Power
0.7kW - 0.8kW (Depending on load)
Efficiency
3.3 L/kW (7 Pints/kW)
Operating Temp
Conditioned Space Limits: 45° F - 95° F
Installed Temp
Location
External Ducted* : 40° F – 140° F
Unducted Reactivation** : 40° F – 100° F
Air Flow
250CFM (See fan curves supplied in appendix)
Supply Air Temp
Space Neutral (± 3° F )
Refrigerant
Refrigerant Charge 28 oz. R410
Unit Size
24 L x 36 W x 16.5 H
Unit Weight
140 lbs.
Shipping Weight
145 lbs
Optional Filtration
Merv 13- Active Electronic
*
* i.e. reactivation and process air inlets are externally ducted and connected to
“normal” non-attic space
**
** i.e. reactivation air comes from the space
Table 1: DryCool™ HD Dehumidifier Specifications
1.4.2. DryCool HD Performance and Psychometric Advantage
65 70 75 80 85
60
50
40
30
25
Entering Temperature ºF
Leaving Dew Point ºF
Entering at 50% RH
Entering at 60% RH
100
80
60
40
50 60 70 80 90
Humidity Ratio Grains of Moisture
per Pound of Dry Air (gr/lb)
Dry Bulb Temperature °F
