10
Delivery conditions and storage
Every humidifier is inspected before being delivered to ensure
good quality. If a humidifier needs to be stored before installa-
t
ion, it must be covered and protected from physical damage as
well as from dust, water and snow. Keep the humidifier in its
packing as long as possible.
•
Humidifiers 060-060 up to 210 are delivered ready
assembled.
• Humidifier with height over 210 cm are delivered
disassembled.
Upon request other sizes can be delivered disassembled.
Note that the stainless-steel self-tapping screws and the cover
plate between the unit casing and the humidifier are not part
of the delivery.
Inspection
Remove the packing material and check that the humidifier
has not been damaged in transport. Damage must be reported
prior to installation.
Transport and lifting
The humidifier must always be handled carefully. Provided that
the packing material has not been removed, the humidifier can
b
e lifted by a crane or fork-lift truck. If a crane is used, meas-
ures must be taken to prevent damage to the cassettes, pump
and discharge pipe.
P
lease note that units larger than the following height (see
Chart 1 below) have cassettes with a weight of more than
25 kg/pc! Be careful when lifting /removing the parts to avoid
injuries.
Caution: Spilled water can cause slippery surface.
When delivered assembled
1. Remove the distribution Headers*.
2. Remove the cassettes and any droplet separator*.
3. Place the reservoir along with the rest of the components in
the AHU unit.
4. Continue at item 2 see below.
* 1-2 if needed small units can in most cases be installed mounted.
Installation
Weight in motion, over 25 kg. Be careful when
moving the parts.
Unit height [cm]
Wet Dry
95% (300 mm) 120 180
85% (200 mm) 150 270
65% (100 mm) 300 —
Chart 1
