Muratec MFX-1300 - Exit Roller P; PDS; Thermistor

5-42
PDS / Thermistor
1. Remove the FIXING UNIT.
2. Remove the FIXING UNIT COVER, and then remove the PDS or the thermistor.
Fxing unit cover
PDF
Themistor
EXIT ROLLER P
1. Remove the FIXING UNIT.
2. Disassemble the FIXING UNIT to remove the EXIT ROLLER P.
Note: Do not bend the PLATE SPRING at removing or attaching the EXIT ROLLER P.
Exit roller P
Plate spring
