Section 78 00-02-0859
2016-06-30 -15-
6. With the USB drive or the SD card installed, press and hold the enter key (bottom right)
on the display for a few seconds as you Power-on the display. The system will boot up
in configuration mode.
7. If you are using a SD card, press the soft key next to the green SD Card icon to select
it. The update file name on the SD card will display.
NOTE: If the SD card is not correctly inserted, an icon showing no SD
card is displayed. Power-off and reinsert the SD card.
NOTE: If you do not see the update file, use the up and down arrows to
view files available. (This is only necessary if other files are also on the
USB or SD drive root directory, which is not recommended.)
8. Press the soft key next to the right arrow to select the file in view. Press again to
confirm. The Progress Bar Screen displays the current download by percent.
To Next Page
