Mutable Instruments ambika Manual

Observe that when you are turning a knob, the explicit name of the parameter is
temporarily shown on the screen:
oscillator
__1
| waveform saw
| waveform saw
wave squa
| para 32
| rang -12
| tune 12
After a short delay, the four names and values are shown again.
Press S1 again to bring the mixer page. L2 lights up in yellow, and the LCD display shows
the following parameters:
Mix 32
| nois 0
| sub 0
| wave squ1
xmod off
| amnt 31
| fuzz 0
| crsh 0
Press S1 again to get back to the oscillators page.
Using the encoder
When Ambika displays a parameters page, the rotary encoder can be used to scroll
through the parameters. The name of the active parameter is capitalized. For example,
oscillator 1 range is here the active parameter:
wave saw
| para 0
| Rang 0
| tune 0
wave squa
| para 32
| rang -12
| tune 12
Rotate the encoder clockwise to make tune the active parameter, rotate the encoder
counter-clockwise to make para the active parameter. If you continue rotating the encoder
clockwise, the next page will become active.
Once a parameter is selected (capitalized), click the encoder to edit it. The full name of the
parameter is displayed on the screen. The encoder can now be used to increment/
decrement the parameter value. Once the value has been set, click the encoder again.
Knob and encoder editing can be combined. Use a knob to rapidly adjust the value of a
parameter, and then, while the parameter name is still displayed on the screen, use the
encoder to fine-tune the value.
Shortcut: Hold the S8 switch while turning the encoder to
increment/decrement values by 8 instead of 1.
10
