- 132 -
TECHNICAL INFORMATION 8
8
Description F4 750 ORO F4 750 S F4 750 S (1+1)
Dry weight (kg) 184 191 192
Fuel tank capacity (l) 20 20 20
Reserve fuel (l) 4 4 4
Oil in crankcase (kg) 3.5 3.5 3.5
PERFORMANCE
Top speed (km/h), over 281 281 281
Average fuel consumption (km/l) 13 13 13
Max. horsepower at rpm (on shaft) kW 93/12,500 kW 93/12,500 kW 93/12,500
cv 126/12,500 cv 126/12,500 cv 126/12,500
Nm 74/10,500 Nm 74/10,500 Nm 74/10,500
Max. torque at rpm Kgm 7.5/10,500 Kgm 7.5/10,500 Kgm 7.5/10,500
ft lb 54.5/10,500 ft lb 54.5/10,500 ft lb 54.5/10,500
ENGINE
Type Four-cylinder, four-stroke
Bore (mm) 73.8 73.8 73.8
Stroke (mm) 43.8 43.8 43.8
Total displacement (cm
3
) 749.4 749.4 749.4
Compression ratio 12 : 1 12 : 1 12 : 1
Starting Electric starter
Cooling system Liquid cooling with water-oil heat exchanger
Specifications
