ADJUSTMENTS 5
5
5.7.1 Spring preload
The adjustment is performed by referring to the
notches. The minimum preload corresponds to
the position where seven notches are in view. The
maximum preload is obtained when one notch is
visible.
5.7.2 Rebound damping hydraulic device
(front suspension)
The adjustment is obtained from the standard
position, which is found by fully turning clockwise
and then anticlockwise (see table). Rotate clock-
wise to increase the damping action or anticlock-
wise to decrease it.
Notches
