- 138 -
TECHNICAL INFORMATION 8
8
8.3. Carbon components ★
1 - Windscreen
2 - Right-hand side fairing
3 - Left-hand side fairing
4 - Undercowl
5 - Tail section
6 - Fuel tank
7 - Filter box
8 - Right-hand air scoop
9 - Left-hand air scoop
10 - Electrical equipment cover (right side)
11 - Electrical equipment cover (left side)
12 - Right-hand side panel
13 - Left-hand side panel
14 - Ignition switch and steering lock cover
15 - Front mudguard
16 - Cooling fan duct
17 - Exhaust pipe guard
18 - Battery support
19 - Heat shield
20 - Lower chain guard
21 - Upper chain guard
22 - Number-plate holder
11
6
1014
1
15
8
17
2 4
712
9
5
13 18 19
22
21
20
316
