MV Agusta F4 - CONTROLS AND INSTRUMENTS; Location of controls and instruments

- 36 -
CONTROLS AND INSTRUMENTS 3
3
3.1 Location of controls and instruments
Instruments and warning lights (§ 3.7)
Clutch lever (§ 5.1)
Left handlebar electrical controls (§ 3.3)
Fuel tank cap (§ 4.6)
Gear lever (§ 3.6 and § 5.1)
Sidestand (§ 3.2)
Ignition switch and steering lock (§ 3.5)
Footrest (§ 5.1)
Rearview mirror (§ 5.1)
Front brake lever (§ 5.1)
Throttle twist grip (§ 3.4)
Rear brake lever (§ 5.1)
Footrest (§ 5.1)
Right handlebar
electrical controls (§ 3.4)
Left side
Right side
