MV Agusta F4 - Page 85

- 85 -
MAINTENANCE 6
6
Fit the side fairing, taking care to position the front
profile as shown in figure A.
Fasten the panel by positioning the tab in the
lower part of the fairing as shown in figure B.
AB
Radiator
Side fairing front
profile
