Specifications Appendix
7-1 Specifications
Cutting Width Max. 450 mm (17.71")
Cutting Height Max. 60 mm (2.36")
Feed Depth Max. 450 mm (17.715")
Min. 40 mm (1.575")
Clamp Electrical Powered
Job Memory 99 Steps, 30 Jobs (Total 300 Steps)
Push-out Length 50 mm (2")
Table Height 900 mm (35.43")
Voltage/Frequency Single Phase 100 V, 50 / 60 Hz
Single Phase 115 V, 60 Hz
Rated Current 100V 50 Hz : 11 A
100V 60 Hz : 15 A
115V 60 Hz : 13 A
Power Consumption 100V 50 Hz : 900 W (Using Transformer)
100V 60 Hz : 1,100 W
115V 60 Hz : 1,100 W
Heat Output 1,460 kJ (350 kcal)
Motors 550 W x 1, 40 W x 1, 70 W x 1
Machine Dimensions 770(W) x 880(D) x 1,510(H) mm (30.4" x 34.7 "x 59.5")
Machine Weight 330 kg (728 lb)
