mycom 3225**C Series User Manual

2202MYJE-MY-C8-N_2018.02.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 3225**C Parts Configuration Table
7-28
P/N
Part Name
Code No.
Remarks
Q’ty.
18-1
Hexagon Socket Head Cap Screw
NB35420-070
M20×70
20
18-2
Hexagon Socket Head Cap Screw
NB35420-065
M20×65
24
19-1
Alignment Pin
NE2013-060
Φ13×60
2
19-2
Alignment Pin
NE2016-070
Φ16×70
2
20
Spring Pin
NE3203-016
Φ3×16
1
22
Balance Piston Cover
CS02200-250
250V**
1
23
Gasket, Balance Piston Cover
CS02300-250N
250***
1
24
Hexagon Socket Head Cap Screw
NB35412-030
M12×30
11
25-1
Male Rotor (1)
CS02520-3225***
3225S*C O-profile,
induction hardening
1 (S*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
CS02520-3225***
3225M*C O-profile,
induction hardening
1 (M*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
CS02520-3225***
3225L*C O-profile,
induction hardening
1 (L*C)
26-1
Female Rotor (1)
25-1
Male Rotor (1)
CS02520-3225***
3225LL* O-profile,
induction hardening
1(LL*C)
26-1
Female Rotor (1)
25-2
Male Rotor (2)
CS02520-3225***
3225*SC O-profile,
induction hardening
1 (*SC)
26-2
Female Rotor (2)
25-2
Male Rotor (2)
CS02520-3225***
3225*MC O-profile,
induction hardening
1 (*MC)
26-2
Female Rotor (2)
25-2
Male Rotor (2)
CS02520-3225***
3225*LC O-profile,
induction hardening
1 (*LC)
26-2
Female Rotor (2)
27-1
Main Bearing (1) O-ring type
CS0270-GRT
320***
2
27-2
Main Bearing (2) O-ring type
CS0270-FRT
250***
2
28-1
Side Bearing (1) O-ring type
CS0280-GRT
320***
2
28-2
Side Bearing (2) O-ring type
CS0280-FRT
250***
2
29-1
Snap Ring (1) C type internal
NG11-200
H200
4
29-2
Snap Ring (2) C type internal
NG11-160
H160
4
30
Balance Piston
CS03000-250
250***
1
31
Key, Balance Piston
CS03100-250
250***
1
32
Snap Ring C type external
NG12-080
S80
1
33
Sleeve, Balance Piston
CS03300-250
250***
1
34
Set Screw
NA83608-020
M8×20
2
35
O-ring
PA11-150
JIS B 2401 P150
1
36
Spacer
CS03600-250
250***
1
37
Snap Ring C type internal
NG11-160
H160
2
38-1
Thrust Bearing (1)
CS03800-320
320***
2
38-2
Thrust Bearing (2)
CS03800-250P
250*** PPS
2
39-1
Lock Nut (1)
NG31-021
AN21
2
39-2
Lock Nut (2)
NG31-017
AN17
2
40-1
Lock Washer (1)
NG32-021
AW21
2
40-2
Lock Washer (2)
NG32-017
AW17
2
42-1
Spacer, Thrust Bearing Alignment (1)
CS04200-B320
320***
2
42-2
Spacer, Thrust Bearing Alignment (2)
CS04200-250
250***
2
43-1
Thrust Bearing Gland (1)
CS04300-320S
320***
2
43-2
Thrust Bearing Gland (2)
CS04300-250S
250***
2
45-1
Hexagon Head Bolt
NB111020-055
M20×55
8
