mycom 3225**C Series User Manual

2202MYJE-MY-C8-N_2018.02.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 3225**C Parts Configuration Table
7-29
P/N
Part Name
Code No.
Remarks
Q’ty.
45-2
Hexagon Head Bolt
NB111016-045
M16×45
8
46-1
Conical Spring Washer
CS04600-320
M20
8
-
Lock Washer (1) Set (old, plate type)
CS0469-G
320*** 8ps/set
-
46-2
Conical Spring Washer
CS04600-250
M16
8
-
Lock Washer (2) Set (old, plate type)
CS0469-F
250*** 8ps/set
-
48
Retainer, Oil Seal
CS04800-320VDS
320V**
1
49
O-ring
PA12-160
JIS B 2401 G160
1
50
Oil Seal
CS05010-320VD
SA1J 95×120×13
1
51
Seal Cover
CS05100-320
320***
1
52
Gasket, Seal Cover
CS05200-320N
320***
1
53
Hexagon Socket Head Cap Screw
NB35416-040
M16×40
8
54-1
Unloader Slide Valve (1-1) (L Port)
-
3225S*C
1 (S*C)
54-1
Unloader Slide Valve (1-1) (M Port)
-
3225S*C
1 (S*C)
54-1
Unloader Slide Valve (1-1) (L Port)
-
3225M*C
1 (M*C)
54-1
Unloader Slide Valve (1-1) (M Port)
-
3225M*C
1 (M*C)
54-1
Unloader Slide Valve (1-1) (L Port)
-
3225L*C
1 (L*C)
54-1
Unloader Slide Valve (1-1) (M Port)
-
3225L*C
1 (L*C)
54-1
Unloader Slide Valve (1-1) (L Port)
-
3225LL*C
1(LL*C)
54-1
Unloader Slide Valve (1-1) (M Port)
-
3225LL*C
1(LL*C)
54-2
Unloader Slide Valve (1-2) (L Port)
-
3225*SC
1 (*SC)
54-2
Unloader Slide Valve (1-2) (M Port)
-
3225*SC
1 (*SC)
54-2
Unloader Slide Valve (1-2) (L Port)
-
3225*MC
1 (*MC)
54-2
Unloader Slide Valve (1-2) (M Port)
-
3225*MC
1 (*MC)
54-2
Unloader Slide Valve (1-2) (L Port)
-
3225*LC
1 (*LC)
54-2
Unloader Slide Valve (1-2) (M Port)
-
3225*LC
1 (*LC)
55-1
Unloader Slide Valve (2-1)
-
320S**
1 (S*C)
55-1
Unloader Slide Valve (2-1)
-
320M**
1 (M*C)
55-1
Unloader Slide Valve (2-1)
-
320L**
1 (L*C)
55-1
Unloader Slide Valve (2-1)
-
320LL*
1(LL*C)
55-2
Unloader Slide Valve (2-2)
-
250S**
1 (*SC)
55-2
Unloader Slide Valve (2-2)
-
250M**
1 (*MC)
55-2
Unloader Slide Valve (2-2)
-
250L**
1 (*LC)
58-1
Hexagon Socket Head Cap Screw
NB35416-050
M16×50
4
58-2
Hexagon Socket Head Cap Screw
NB35412-040
M12×40
4
59
O-ring
PA11-032
JIS B 2401 P32
1
60-1
Unloader Cylinder (1)
-
3225S*C
1 (S*C)
60-1
Unloader Cylinder (1)
-
3225L*C
1(M*C)(L*C)
60-2
Unloader Cylinder (2)
-
250S,250L
1 (*SC)(*LC)
60-2
Unloader Cylinder (2)
-
250M
1 (*MC)
61
Hexagon Socket Head Cap Screw
NB35416-040
M16×40
2
62-1
Hexagon Socket Head Cap Screw
NB35420-070
M20×170
8
62-2
Hexagon Socket Head Cap Screw
NB35416-090
M16×90
6
63-1
O-ring
PA12-170
JIS B 2401 G170
1
63-2
O-ring
PA12-190
JIS B 2401 G190
1
64-1
Unloader Piston (1)
CS06400-3225CK
3225**C
1
64-2
Unloader Piston (2)
CS06400-250T
250***
1
65-1
O-ring
PA11-140
JIS B 2401 P140
1
