mycom 3225**C Series User Manual

2202MYJE-MY-C8-N_2018.02.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 3225**C Parts Configuration Table
7-30
P/N
Part Name
Code No.
Remarks
Q’ty.
65-2
O-ring
PA11-155
JIS B 2401 P155
1
66-1
Teflon Cap Seal
CS06600-3225
SUNR-BE-140(S4101)
1
66-2
Teflon Cap Seal
CS06600-250
SUNR-BE-155(S4101)
1
67-1
Push Rod, Unloader Slide Valve (1)
CS06700-3225SSC
3225S*C
1 (S*C)
67-1
Push Rod, Unloader Slide Valve (1)
CS06700-3225C
3225L*C,M*C,LL*C
1(M*C)(L*C)
67-2
Push Rod, Unloader Slide Valve (2)
CS06700-3225C2
3225*SC
1 (*SC)
67-2
Push Rod, Unloader Slide Valve (2)
CS06700-3225MC2
3225*MC
1 (*MC)
67-2
Push Rod, Unloader Slide Valve (2)
CS06700-3225C2L
3225*LC
1 (*LC)
68-1
Guide Pin (1)
NE2506-016
Φ6×16
1
68-2
Guide Pin (2)
NE2506-012
Φ5×12
1
69-1
Lock Nut (1)
NG31-010
AN10
1
69-2
Lock Nut (2)
NG31-008
AN08
2
70-1
Lock Washer (1)
NG32-010
AW10
1
70-2
Lock Washer (2)
NG32-008
AW08
2
71
Lock Nut
NG31-012
AN12
1
72
Lock Washer
NG32-012
AW12
1
73-1
O-ring
PA11-044
JIS B 2401 P44
1
73-2
O-ring
PA12-035
JIS B 2401 G35
1
74-1
Unloader Cover (1)
CS07400-3225C
3225**C
1
74-2
Unloader Cover (2)
CS07400-250S
250***
1
75-1
O-ring
PA12-150
JIS B 2401 G150
1
75-2
O-ring
PA12-170
JIS B 2401 G170
1
76-1
Hexagon Socket Head Cap Screw
NB35412-035
M12×35
8
76-2
Hexagon Socket Head Cap Screw
NB35412-030
M12×30
8
77-1
Indicator Cam (1)
-
3225S*C
1 (S*C)
77-1
Indicator Cam (1)
-
3225M*C
1 (M*C)
77-1
Indicator Cam (1)
CS07700-3225C
3225L*C
1 (L*C)
77-2
Indicator Cam (2)
CS07700-250S
250S**
1 (*SC)(*LC)
77-2
Indicator Cam (2)
-
250M**
1 (*MC)
78
Ball Bearing
CS07800-200
#6000
2
79
Snap Ring C type external
NG12-010
S10
2
80
Bearing Gland
CS08000-200
200***
2
81
Hexagon Socket Head Cap Screw
NB35406-015
M6×15
6
82
V-ring
CS08200-200B
VH10 NBR
2
83
Spring
CS08300-200
200***
2
84
Retainer, Indicator Cam Spring
CS08400-200
200***
2
85
Oil Injection Pipe
-
3225S*C
1 (S*C)
85
Oil Injection Pipe
-
320M**
1 (M*C)
85
Oil Injection Pipe
-
320L**
1 (L*C)
86
O-ring
PA12-030
JIS B 2401 G30
1
87-1
Guide Block (1)
CS08700-320
320***
1
88-1
Stem, Guide Block (1)
87-2
Guide Block (2)
CS08700-250
250***
1
88-2
Stem, Guide Block (2)
89-1
O-ring
PA11-024
JIS B 2401 P24
2
89-2
O-ring
PA11-020
JIS B 2401 P20
2
91
Shaft Key
CS09100-320
320***
1
