mycom 3225**C Series User Manual

2202MYJE-MY-C8-N_2018.02.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 3225**C Parts Configuration Table
7-32
P/N
Part Name
Code No.
Remarks
Q’ty.
166-1
Hexagon Socket Head Cap Screw
NB35496-015
M6×15
4
166-2
Hexagon Socket Head Cap Screw
NB35405-012
M5×12
4
168
Pipe Guide, Oil Injection
CS16800-3225C
3225L*C,M*C,S*C
1
168
Pipe Guide, Oil Injection
-
3225LL*C
1(LL*C)
197
O-ring
PA11-058
JIS B 2401 P58
1
215-1
Flange, Lubricating Oil Supply (1)
with hole
CS71300-040MK
JIS 20K 40A (1"1/2)
1
215-1
Flange, Lubricating Oil Supply (1)
without hole
CS71300-040
JIS 20K 40A (1"1/2)
1
215-2
Flange, Lubrication Oil Supply (2) with
hole
CS71300-025MK
JIS 20K 25A (1")
1
215-2
Flange, Lubricating Oil Supply (2)
without hole
CS71300-025
JIS 20K 25A (1")
1
216-1
Gasket, Lubricating Oil Supply Flange
(1)
CS71200-040N
JIS 20K 40A
1
216-2
Gasket, Lubricating Oil Supply Flange
(2)
CS71200-025N
JIS 20K 25A
1
217-1
Hexagon Head Bolt
NB12016-045
M16×45
4
217-2
Hexagon Head Bolt
NB12016-045
M16×45
4
218
Flange, Injection Oil Supply with hole
CS71300-020MK
JIS 20K 20A (3/4")
1
218
Flange, Injection Oil Supply without hole
CS71300-020
JIS 20K 20A (3/4")
1
219
Gasket, Injection Oil Supply Flange
CS71200-020N
JIS 20K 20A
1
220
Hexagon Head Bolt
NB12012-035
M12×35
4
237-1
Torsional Slip Washer (1)
CS23700-320
320***
2
237-2
Torsional Slip Washer (2)
CS23700-250
250***
2
245-
Spring Washer
ND330-12
M12
5
250-1
Thrust Washer (1)
CS25000-320
320***
2
250-2
Thrust Washer (2)
CS25000-250
250***
2
267-1
Special Spring Washer for Hexagon
Socket Head Cap Screw
ND330-16
M16
4
267-2
Special Spring Washer for Hexagon
Socket Head Cap Screw
ND330-12
M12
4
326-1
Gland, O-ring (1)
CS32600-3225C
3225**C
1
326-2
Gland, O-ring (2)
CS32600-3225C2
3225**C
1
328
O-ring
PA11-046
JIS B 2401 P46
1
329
Spring Pin
NE3204-010
Φ4×10
1
350
Flange, Balance Piston Oil Return
Piping with hole
CS71300-020MK
JIS 20K 20A (3/4")
1
350
Flange, Balance Piston Oil Return
Piping without hole
CS71300-020
JIS 20K 20A (3/4")
1
351
Gasket, Balance Piston
CS71200-020N
JIS 20K 20A
1
352
Hexagon Head Bolt
NB12012-035
M12×35
4
353
Flange, Bearing Cover Oil Return Piping
with hole
CS71300-032MK
JIS 20K 32A( 1-1/4”)
1
353
Flange, Bearing Cover Oil Return Piping
without hole
CS71300-032
JIS 20K 32A (1-1/4”)
1
354
Gasket, Bearing Cover
CS71200-032N
JIS 20K 32A
1
355
Hexagon Head Bolt
NB12016-045
M16×45
4
356
Flange, Rotor Casing Oil Return Piping
with hole
CS71300-032MK
JIS 20K 32A (1-1/4”)
1
356
Flange, Rotor Casing Oil Return Piping
without hole
CS71300-032
JIS 20K 32A (1-1/4”)
1
357
Gasket, Rotor Casing
CS71200-032N
JIS 20K 32A
1
358
Hexagon Head Bolt
NB12016-045
M16×45
4
420
Spacer, Unload Position (High-stage)
CS42000-250S30
250S** 30 % load
1 (*SC)
420
Spacer, Unload Position (High-stage)
CS42000-250M30
250M** 30 % load
1 (*MC)
