mycom UD Series User Manual

Chapter 7 Related Documents
UD-series Screw Compressor 7.2 Parts Configuration Table 125*UD
7-10
P/N
Part Name
Code No.
Remarks
Q’ty.
92
Suction Cover Flange MYK100A without
hole
CS71400-P100
MYK100A(4")
Male
1
93
Gasket, Suction Flange
CR72000-100N
MYK100A
1
94
Hexagon Head Bolt
NB12022-055
M22×55
4
95
Discharge Cover Flange
MYK65CD
CS71400-P065CD
MYK65CD Male
1 (*UD)
96
Gasket, Discharge Flange
CS72000-065N
MYK65A
1 (*UD)
97
Hexagon Head Bolt for MYK65CD Flange
NB12016-045
M16×45
4 (*UD)
97
Hexagon Head Bolt for MYK65A Flange
-
M16×70
4 (*UD)
98
Spring Pin
NE3203-014
φ3×14
2
100
Mechanical Seal Assembly (BOS-T1)
CS10000-125BT
BOS-T1
1
100
Mechanical Seal Assembly (BBSE)
CS10002-125EBS
BBS-E
1
100
Mechanical Seal Assembly (UV4)
CS10009-125-F70
UV4
1
100
Mechanical Seal Assembly (BBS3)
CS10001-125BBS
BBS3
1
100 Mechanical Seal Assembly (BOS)
CS10000-125BT-F7
0
BOS 1
100
Mechanical Seal Assembly (BBS3)
CS10001-125BBS
BBS3
1
120
Unloader Indicator Assembly
CS12000-125F
125, 0-100 %
1
120
Unloader Indicator Assembly
CS12000-125H
125, 0-50 %
1
125 Micro Switch Set CS12501-IND0203
125,1612 shared
right
1
127 Micro Switch Cam CS12700 ｰ 125F 125, 0-100 % 1
127
Micro Switch Cam
CS12700-125H
125, 0-50 %
1
129 Potentiometer CS1299-E10
200-1K with lead
wire
1
129 Conductive Potentiometer CS12919-E10
200-1K with lead
wire
1
164 Pipe Gland, Oil Injection CS16400-160 160*** 1
166 Hexagon Socket Head Cap Screw NB35405-012 M5×12 2
235 Spacer, Discharge Flange FX101-125 1
236 Gasket, Discharge Flange Spacer CS23600-125N 1
237 Torsional Slip Washer CS23700-125 125*** 2
246 Guide, Unloader Slide Valve CS24600-125 125*** 1
247 Hexagon Socket Head Cap Screw NB35406-045 M6×45 3
248
Spring Washer, Hexagon Head Cap
Screw
ND330-06 M6 3
249
Alignment Pin
NE2006-035
φ6×35
2
250
Thrust Washer
CS25000-125
125***
2
251
Flange (for Electromizer)
CR74000-015
MYK15A(1/2")
1
252
Gasket, Flange (for Electromizer)
CR72000-015N
1
253
Hexagon Head Bolt
NB111012-035
M12×30
2
253
Hexagon Head Bolt
NB111012-030
M12×30
2
254
Flange (for Aquamizer)
CR74000-010
MYK10A(3/8")
1
255
Gasket, Flange (for Aquamizer)
CR72000-010N
1
256
Hexagon Head Bolt
NB111012-030
M12×30
2
267
Spring Washer, Hexagon Head Cap
Screw
ND330-06 M6 4
605
Plug
NF06-015
R1/2
1
607
Plug
NF06-004
R1/8
1
715
Blind Plate for Electromizer
CS71500-010
10A
1
715
Blind Plate for Aquamizer
CS71500-010
10A
1
