4. SPECIFICATIONS
4.1. TECHNICAL SPECIFICATIONS
The device is designed to operate in environmental conditions that are typical of covered working areas and within
the parameters under IEC 60601-1.
General characteristics
Image format
Bitmap file 4096 grey levels, compatible with Windows / Mac
(PNG, JPG)
Image transfer
via USB cable, according to TWAIN® standard, in single and
multiple picture mode
Power input
5V DC 500mA max, USB powered
Stand-alone sensor: 1 W
Sensor integrated in dental unit: 2.5 W
USB interface characteristics
USB 2.0 High Speed
Protection class
IP67 (only the sensor and its cable, not the USB connector)
IPX0 (for all the other parts of the product)
Operation
Continuous
Sensor general characteristics
Technology
CMOS
Type of scintillator
Caesium Iodide scintillator: CsI(TI)
Pixel dimensions (H x V)
20 x 20 µm
Pixel pitch
20 µm
Maximum nominal resolution
25 lp/mm
Dynamic range
57 dB
Tensile strength
100 N
Maximum irradiation
57.6 Gy (@ T = 25°C, 60 kVp)
Air Kerma necessary for intended use
min 0.4 mGy, max 1.1 mGy
Cable length
2.5 ± 0.1 m
Cable diameter
3.7 ± 0.3 mm
Useful lifespan
50,000 shots at max 1.1 mGy
Sensor characteristics: Size 1
Image dimensions (H x V)
20 x 30 mm
Number of pixels (H x V)
1000 x 1500
Dimensions (H x V x T)
39.0 x 25.0 x 12.5 mm
(tolerance: ± 0.3 mm)
Sensor characteristics: Size 2
Image dimensions (H x V)
26 x 34 mm
Number of pixels (H x V)
1300 x 1700
Dimensions (H x V x T)
41.9 x 30.4 x 12.8 mm
(tolerance: ± 0.3 mm)
Characteristics of the interface on dental unit
Dimensions (H x V x T)
162 x 122 x 109 mm excluding sensor cable
Weight
approx. 220g
Operating conditions
Temperature
from 0°C to +35°C
RH (humidity)
from 0% to 70%
