- Any computer, monitor, printer, mouse, keyboard and any other device connected to the device must be
compliant with ISO, IEC, EN or local standards.
- The Manufacturer is not responsible for problems or malfunction of parts and/or components not approved by
itself, not complying with the regulations and not installed by qualified technical personnel acknowledged by
the Manufacturer.
- Do not use electronic equipment in proximity of life support equipment (e.g. pacemakers or heart stimulators)
and hearing aids. Before using any electronic device in health facilities, always check that it is compatible
with the other equipment present.
Use the X-ray system associated with the sensor in compliance with national provisions on protection from
ionising radiation, such as:
(a) Each examination must be justified by evidence that the benefits outweigh the risks.
(b) Patients must wear leaded aprons with collar for thyroid protection.
(c) Before the examination, ask women of childbearing age if they are pregnant or if there is a possibility that
they can be. If so, the patient should not undergo the examination, unless she has seen a radiologist
belonging to an accredited hospital facility in order to evaluate, together with the patient and operator, the
benefits and risks associated with this type of procedure, taking into consideration the possibility to make
other types of examination.
(d) The operators must keep a safe distance, protect themselves with proper shielding and stay close to the
patient in the examination room only in the rare cases where the patient needs assistance. In the event that
the operators must remain in the examination room, they must protect themselves with a leaded apron
featuring a collar for thyroid protection.
(e) Inform the patient of the risks associated with the examination, acquire its informed consent and store
the related document.
In case of claims or for technical assistance, users in Brazil are required to contact the following email
address: servico.odontologico@cefla.it.
Users in the US are required to use the following contact information:
Cefla North America Inc.,
6125 Harris Technology Blvd., Charlotte, NC, 28269 United States
Phone: +1 704 598 0020, e-mail: info@ceflaamerica.com
The sensor system is directly powered by the Personal Computer USB
®
port. Therefore, it is necessary that the PC is
turned on and the sensor cable (in the case of ZEN-X model) or the electronic interface (in the case of the ZEN-Xi
model) is connected to a USB
®
port. If the ZEN-Xi system is installed in a dental chair equipped with integrated
Workstation, the above connections have already been made inside the dental chair’s system; therefore, just turn on
the workstation.
Insert the A-type USB
®
connector inside a free USB
®
port of the Personal Computer.
WARNING: It is possible to operate only if iCapture is turned on (see the iCapture manual for details about
installation and use).
1.6.3. USE OF THE CENTERING DEVICE
The sensor must be held in the correct position using a centering device in order to obtain good x-ray images.
Kits of special centering devices for front, rear, bite-wing periapical images and for endodontics are available on the
market. The individual components in the kits are also available as spare parts. Contact the dealer who supplied the
sensor to purchase spare centering devices.
In addition, universal centering devices such as RINN
®
Uni-Grip or KerrHawe
®
series Bite Senso or similar can be
used.
Always refer to the instructions included with the centering kit for details on use, cleaning and sterilization of the
centering device.
WARNING: NEVER grasp the sensor with grippers to avoid irreparable damage. Always use centering
devices specifically designed for use with digital x-ray sensors.
Always sterilize the centering device before using it with a patient. For centering device cleaning and
sterilization instructions, follow the conditions specified by centering device manufacturer.
