Myson iVector S2 - 2-Way Valve: Pressure Drop Data; Pressure Drop Diagram Explanation


iVector S2
Installation manual
iVector S2 • 2022-07-01
US
Pressure drop diagram
Pressure drop figures based on the 2 way valve fully open position.
Kv &
Cv
14.5
13.1
10.2
7.3
4.4
1.3
1.0
0.7
0.4
8.7
8.5
2.9
1.5
0.9
0.6
0.3
1.2
0.1
psi
0.1 0.2 0.4 0.5 0.75 1.0 1.5 1.75 3.0 4.0 8.0
Flow rate in US gallons per minute / gpm
Cv = 4.17 gpm
qm = kg/h
KV
S
= 3.60
