Model 710 Swing Door System
NABCO
ENTRANCES INC 877-622-2694 www.nabcoentrances.com - 4 -
DN0036
To The Installer The purpose of this manual is to familiarize the purchaser with the proper
installation and operation of this system. It is essential that this equipment be
properly installed and operational before the door is used by the public. It is the
purchaser’s responsibility to inspect the operation of the entrance system to be
sure it complies with any applicable standards. In the United States, ANSI
Standard 156.19 usually covers this type of door. Other local standards or codes
may apply. Use them in addition to the ANSI Standard. The GT 710 is listed
with the Underwriters Laboratory and is identified as such on the label.
Instruct the building owners/operator on the essentials of the operation of the door
and this device. The owner should follow these instructions to determine whether
the door is operating properly and should immediately call for service if there is
any malfunction.
All installation changes and adjustments must be made by qualified, NABCO
trained technicians.
Overview Earlier version of the NABCO GT710 can be retrofitted with the newer Magnum
Control Board (Magnum IV). This combination offers several control features
that accommodate most installations.
This Manual offers step-by-step instructions on how to upgrade an existing
GT710 installation with the Magnum IV and related hardware.
Figure 1 – Overview of GT710 with Magnum IV
